Vespa LX 50 4T User Manual

Engine oil top-up
Always check oil level before carrying out top-ups and add oil without exceeding the
MAX level. An engine oil check-up and top-up should be carried out every 3,000 km
at an Authorised Piaggio Service Centre.
Engine oil change (03_03)
Change oil and clean the filter after every 6,000 km at an Authorised Piaggio Service
Centre. Empty the engine by draining the oil through drainage cap «C» with a cold
engine. First unscrew the cap-dipstick used to check engine oil level, then cap «C»
and take out the mesh filter. After cleaning and mounting again the mesh filter, screw
cap «C» and fill with oil the hole of the cap-dipstick used to check engine oil level.
Then start up the scooter, leave it running for a few minutes and switch it off: 5 minutes
later check oil level and, if necessary, add oil without exceeding the MAX level. Only
use new oil of the recommend type for oil top-ups and change.
CAUTION
USED OILS CONTAIN SUBSTANCES HARMFUL TO THE ENVIRONMENT. FOR
OIL REPLACEMENT, CONTACT AN AUTHORISED PIAGGIO SERVICE CENTRE,
AS THEY ARE EQUIPPED TO DISPOSE OF SPENT OILS IN AN ENVIRONMEN-
TALLY FRIENDLY AND LEGAL WAY.
Recommended products
AGIP CITY HI TEC 4T
Engine oil
SAE 5W-40, API SL, ACEA A3, JASO MA Synthetic oil
27
3 Maintenance

Vespa LX 50 4T Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	49.9 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Front Brake	200 mm disc
Rear Brake	110 mm drum
Front Tire	110/70 - 11"
Rear Tire	120/70 - 10"
Height	1, 140 mm
Transmission	Automatic
Fuel Tank Capacity	7 liters
Seat Height	785 mm
Dry Weight	96 kg
Max Power	4.35 hp @ 8, 250 rpm
Length	1, 770 mm
Width	705 mm
Front Suspension	Single arm with helical spring and hydraulic shock absorber
