White anhydrous-calcium based grease to protect
roller bearings; temperature range between -20 °
C and +120 °C; NLGI 2; ISO-L-XBCIB2
Steering bearing
Removal
- Use the specific tool both to remove the lower seat of the upper bearing and to remove the upper seat
of the lower bearing fitted on the chassis.
N.B.
TO REMOVE THE LOWER SEAT OF THE LOWER STEERING BEARING JUST USE A SCREW-
DRIVER AS A LEVER BETWEEN THE SEATING AND THE SLEEVE.
Specific tooling
020004Y Punch for removing fifth wheels from headstock
- Remove the fifth wheel fitting and the dust guard
on the steering tube as shown in figure, using the
specific tool. Proceed giving a few taps with the
mallet.
Specific tooling
020004Y Punch for removing fifth wheels from
headstock
- Refit the fifth wheel fitting and the dust guard on
the steering tube until they stop, using the specific
tool.
Specific tooling
006029Y Punch for fitting fifth wheel seat on
steering tube
Rear
Removing the rear wheel
-Straighten the split pin and remove the cap.
-Remove the wheel acting on the central fixing point.
Suspensions LXV 125
SUSP - 158
