Vespa LXV 125 User Manual

Brakes
BRAKES
Specification Desc./Quantity
Front brake Disc brake (Ø 200 mm) with hydraulic control (lever on the far
right of the handlebar) and fixed calliper.
Rear brake Ø110 mm drum brake
Wheels and tyres
WHEELS AND TYRES
Specification Desc./Quantity
Front wheel rim Die-cast aluminium alloy; 2.50 x11"
Front tyre Tubeless; 110/70-11"
Rear wheel rim Die-cast aluminium alloy; 3.00 x 10"
Rear tyre Tubeless; 120/70-10"
Front tyre pressure 1.6 bar
Rear tyre pressure 2 bar
Rear wheel pressure (rider and passenger): 2.3 bar
Carburettor
CARBURETTOR SETTING
Specification
Desc./Quantity
Type CVEK26
Body stamping CVK
Throttle valve diameter Ø 26.5
Diffuser diameter Ø 26.4
Maximum jet 82
Maximum air jet (on the body) 85
Tapered pin stamping NELA
Throttle valve spring 130 ÷ 180 gr.
Minimum jet 35
Idle air jet (on the body) 150
Idle mixture adjustment screw initial opening 2
Starter jet 42
Starter air jet (on the body) Ø 1.5
Starter pin travel 10 mm (at 24°)
Starter resistance 20 Ohm (at 24°)
Kehin
CARBURETTOR SETTING
Specification
Desc./Quantity
Type CVEK26
Body stamping CVK
Throttle valve diameter Ø 26.5
Diffuser diameter Ø 26.4
Maximum jet 82
Maximum air jet (on the body) 85
Tapered pin stamping NELA
Throttle valve spring 130 ÷ 180 gr.
Minimum jet 35
Idle air jet (on the body) 150
Idle mixture adjustment screw initial opening 2
Starter jet 42
Starter air jet (on the body) Ø 1.5
LXV 125 Characteristics
CHAR - 9

Vespa LXV 125 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Seat Height	785 mm
Max Torque	9.6 Nm at 6, 000 rpm
Length	1, 770 mm
Front Brake	200 mm disc brake
Rear Brake	110 mm drum brake
Weight	114 kg
Top Speed	91 km/h
Transmission	Automatic CVT
Rear Suspension	Coil spring and hydraulic shock absorber
