Instrument panel
- Remove the front grille
- Remove the shield back plate
- Remove the two fixing screws of the instrument
panel.
- Remove the odometer cable.
- Remove the connector of the electric connections
from the instrument panel
Instrument panel lower shell
- Remove the instrument panel
- Remove the handlebar
- Remove the two screws indicated in the figure.
- Remove the screw indicated in the figure, placed
under the handlebar light fitting
LXV 125 Chassis
CHAS - 175

Vespa LXV 125 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Seat Height	785 mm
Max Torque	9.6 Nm at 6, 000 rpm
Length	1, 770 mm
Front Brake	200 mm disc brake
Rear Brake	110 mm drum brake
Weight	114 kg
Top Speed	91 km/h
Transmission	Automatic CVT
Rear Suspension	Coil spring and hydraulic shock absorber
