Seat
Remove the saddle opening cable
Remove the four screws shown in the figure and
the rear seat from the chassis saddle.
Unscrew the two screws of saddle fixing hook cov-
er.
To remove the cable and the sheath:
- Remove the elastic ring and unscrew the cable
end from the seat on the saddle fixing hook.
- Remove the other end of the cable from the fixing
seat on the locking block.
Chassis LXV 125
CHAS - 174

Vespa LXV 125 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Seat Height	785 mm
Max Torque	9.6 Nm at 6, 000 rpm
Length	1, 770 mm
Front Brake	200 mm disc brake
Rear Brake	110 mm drum brake
Weight	114 kg
Top Speed	91 km/h
Transmission	Automatic CVT
Rear Suspension	Coil spring and hydraulic shock absorber
