Refitting the rear wheel

- Fit the wheel, tighten the nut to the prescribed

torque.

- Refit the cap and the split pin folding it correctly

as shown in the figure.

Locking torques (N*m)

Locking torque 137 ÷ 152 Nm

Swing-arm

Removal

Remove the swinging arm acting on the three

clamps shown in the figure.

LXV 125 Suspensions

SUSP - 159

Questions and Answers:

Need help?

Do you have a question about the Vespa LXV 125 and is the answer not in the manual?

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Seat Height	785 mm
Max Torque	9.6 Nm at 6, 000 rpm
Length	1, 770 mm
Front Brake	200 mm disc brake
Rear Brake	110 mm drum brake
Weight	114 kg
Top Speed	91 km/h
Transmission	Automatic CVT
Rear Suspension	Coil spring and hydraulic shock absorber
