Page 3-2 Mastertech 3100 Operator’s Manual
MASTERTECH FEATURES
The Mastertech Multi-Function Tester can be hand-held or placed on a flat surface. An adjustable hand strap
on the back provides added security while holding the tester.
A built-in support stand allows the tester to be tilted to the most convenient viewing angle when it is not
handheld.
FIGURE 3-1. Tester Features
DISPLAY
LEDs
KEYBOARD
RS232 PORT
DLC
INSTRUMENTATION PORT
NiCAD BATTERY PACK
POWER CONNECTOR
SCREEN CONTRAST
PROGRAM CARD
CARTRIDGE
SLOT
CONTROL
