Mastertech Kit Components
Page 3-12 Mastertech 3100 Operator’s Manual
PRINTER
When the tester is connected to a compatible serial printer, such as the optional VP-411/VP-414, the
following functions are available:
• Print diagnostic parameters
• Print trouble codes
• Print test results
• Print display information (including bar graphs and plots)
REMOTE
HOST COMPUTER
VP-411 / VP-414
PRINTER
TESTER
FIGURE 3-9. RS232 Port Devices
