Maintenance
67
Cutting disc
Safety concerning maintenance work on the cutting unit
When working on the cutting unit, the tractor must be stopped and
secured.
This prevents the machine from suddenly starting to rotate.
If the tractor and the PTO shaft have not been connected following the
instructions serious accidents causing damage to limbs can occur.
When working on the cutting unit:
• The tractor engine must be stopped.
• The ignition key must be removed.
• The PTO shaft must be disconnected.
• The tractor hydraulic system must be disconnected.
• The hand brake must be activated.
After 1 hour of use
Thereafter, every day
The cutting discs are checked as follows:
»Maintenance intervals« page 56
Pull and release the lock.
Open the front guard.
Use a suitable wrench to tighten the cutting disc to the torque
shown.
Loctite
242
80 Nm +/- 5
59 ft/lb. +/- 3
Loctite 242
