38
Assembly - attachment
PTO shaft
> Fit the PTO shaft.
> Check that the PTO shaft's two halves overlap one another by a
minimum of 200 mm when the shaft is fitted between the tractor
and the machine.
> Also check the length of the PTO shaft with the machine in the
raised position.
NB
When shortening the PTO shaft, refer to the manufacturer's
instructions supplied with the PTO shaft.
> The bracket for the PTO shaft is turned in as shown.
NB
After the machine is coupled, the bracket must be turned in as shown.
NB
It is important that the bracket is turned in as shown after the machine
is coupled, as there is a high risk that the PTO shaft could be
damaged.
