Vicon EXTRA 632 FR - Page 32

32
Assembly - attachment
> Raise the machine to the height shown of 700 mm.
> The chains* shown are tightened so the position is locked.
* Extra equipment
 »Optional equipment« page 119
> Release the support legs on both sides of the hitch as shown.
700 mm
Chain
Support leg
