Maintenance
91
> Fit the guard around the cutterbar's transmission.
> Remove the guard on the opposite side of the cutterbar.
> Remove the top cover on the cones found on the opposite side of
the cutterbar.
> Clean the inside of the cone.
> Fit the cone's top cover.
Guard
Guard
Top cover
