Maintenance
101
Centre gear
Checking the oil level
Every 80 hours of use
CR model only
»Maintenance intervals« Page 84
The oil level is checked as follows:
Remove oilplug 2.
Check that the oil reaches the edge of the hole for oilplug 2.
When topping up, remove oilplug 1.
Fill the oil through the hole for oilplug 1.
• The correct oil level is reached when the oil reaches the edge of
the hole for oilplug 2.
Fit oilplugs 1 and 2 and tighten them.
»Lubricants« Page 177
