Vicpas UniOP ePAD05 - Installation; Phisical Dimensions

UniOP
12
Installation
UniOP panels are designed to be mounted on the front of some type of enclosure. The
bezel height, bezel width and the cut-out dimensions for each panel type are given in
the following pages.
Note: remove the red BATTERY PROTECTION strip before installation
Phisical Dimensions
All measurements are given in mm, with tolerance ±0.5.
MD02R-04
195mm
7.67 "
8mm
0.31"
9
8
m
m
3
.
8
5
"
8
7
m
m
3
.
4
3
"
184mm
7.24 "
174mm
6.85 "
5.0mm
0.20 "
4
.
5
m
m
0
.
1
8
"
4x 4. 2mm
0.16"
A = 74mm 2.91” for operator panel which have suffix A6, A7, 45.
82mm 3.2” for operator panel which have suffix 50
Figure 1 - Dimensions
