UniOP
54
In case the memory card needs to be removed from the slot and carried around, it has
to be kept in a special antistatic protective case.
Getting Started
UniOP panels must be programmed with the programming package Designer.
To program a panel you will have to connect the panel to a personal computer
running Designer software package; the panel must be in Configuration mode to be
programmed. Use the cable CA2/CA114 to connect the panel to a personal computer.
The software package Designer is a Windows
TM
application and must be properly
installed. The Windows
TM
environment is not included in the software package
Designer and must already be installed on the personal computer.
The software package can use either the communication ports COM1 or COM2 on
the personal computer. Check that the Designer program is correctly configured to
comunicate with the communication port to which the cable attached.
The communication parameters between the panel and the personal computer are:
speed: 9600 (models PC/Printer Port support also speeds of
19200 and 38400 baud )
parity: none
stop bit: 1
The Designer software defaults to the correct parameters.
The version of the Designer being used must be compatible with the firmware version
of the panel to be programmed. Call for more information on compatibility between
firmware and programming software.
