Vicpas UniOP ePAD05 - Technical Specifications; Environmental and EMC Specifications

Installation Guide
3
Technical Specifications
Power supply voltage DC 18 - 30 V
Power consumption
(1)
Back-up battery
(1)
3 V 270mA Lithium, not rechargeable,
life about 1 year, user replaceable,
model: CR2430.Change with same battery or
equivalent with the work temperature of UniOP.
(for eTOP04C 3V 50mAh Lithium, rechargeable,
not user-replaceable, model VL2330)
Fuse 2 A T user replaceable
(except the models CP10G-04, ePAD03/04/05/06,
MKDG-06, ePAD33C and
eTOP03/04/05/06/20/33/40/50 that are equipped
with an overcurrent protection device)
Environmental conditions
Operating temperature
0 ÷ +50°
C, with the exception of
the model indicated on note
(2)
EN 60068-2-14
Storage temperature
-20 ÷ +70°C
EN 60068-2-14
Operating and storage humidity
5 ÷ 85 % RH not-condensing
EN 60068-2-30
Vibrations
5 ÷ 9 Hz, 7mm peak
9 ÷ 150 Hz, 1 G
EN 60068-2-6
Shock 50 G, 11 ms, 3 pulses per axis EN 60068-2-27
Protection class IP65 front panel
(3)
EN 60529
Keyboard reliability > 3 million operations
Touch screen tecnology Resistive
Touch screen reliability > 1 million operations
Electromagnetic Compatibility (EMC)
Emitted interference Class A EN 55011
Radiated, radio-frequency,
electromagnetic field immunity test
80 MHz ÷ 1 GHz, 10 V/m
1,4GHz ÷ 2 GHz, 3V/m
2GHz ÷ 2,7 GHz, 1V/m
EN 61000-4-3
Burst immunity test
Surge immunity test
±2 KV DC power supply
±1 KV signal lines
±0,5 KV DC power port (line to
earth)
±1 KV signal line (line to earth)
EN 61000-4-4
EN61000-4-5
