Vicpas UniOP ePAD05 - Installation Procedures

UniOP
52
Installation Procedures
Place the four fixing brackets on the longer side near the corners, as shown in figure
(Figure 48). Screw each fixing screw until the plastic or aluminium bezel corner get in
contact with the panel.
FIXING BRACKET
Figure 45 – Fixing bracket position
