Vicpas UniOP ePAD05 - Port and Internal Feature Specifications

UniOP
4
Electrostatic discharge immunity test
Immunity to conducted disturbances
inducted by radiofrequency field
Voltage dips, short interruptions and
voltage variations immunity test
8 KV (air electrostatic
discharge)
4KV (contact electrostatic
discharge)
0.15 ÷ 80 MHz, 12 V
Port : AC mains; Level :
100% duration : 1 cycle and 250
cycles (50Hz) ;
40% duration : 10 cycles (50Hz)
70% duration : 25 cycles (50Hz)
Phase : 0°-180°
EN 61000-4-2
EN61000-4-6
EN61000-4-11
PC/Printer Port
(1)
RS-232connector D-sub 15 pin female
300 - 38400 baud
PLC Port RS-232, RS-422, RS-485, C.L. 20 mA (active),
connector D-15 pin male
300 - 38400
(1)
baud
AUX Port connector D-9 pin female (functionality can be
configured with an optional communicatin
module)
User memory
(
1)
Recipe memory
(1)
16 KB / 32 KB RAM with back-up battery
Hardware clock
(1)
Clock/Calendar with back-up battery
Alarms
(1)
256/1024
Historical event list
(1)
last 256/1024 events with back-up battery
Programming software Designer version 6
Notes:
(1) feature depends on the panel models; see Table 1.
(2) for models with “B7” suffix range -20 ÷ +60°C
for eTOP and ePAD range 0 ÷ +45°C
(3) all the installation instructions listed in the chapter ‘Installation
Environment’ must be followed in detail.
