eTOP05, eTOP05EB, eTOP06
P
O
W
E
R
PLC PORT
PC PRINTER
AUX PORT
Figure 28 - Connectors
eTOP06C, eTOP20C, eTOP33C, eTOP40C, eTOP50C
1. Power
2. Aux Port
3. PLC Port
4. PC/Printer Port
5. Ethernet Port
6. USB Port (only for )
Figure 29 - Connectors
