Victor C6000 User Manual

Page 31
RISE
Example: Find the rise given a 7 Inch pitch and a run of 12 Feet 6 Inches
KEY INPUT & DISPLAY
0
PTCH 7
Inch
RUN 12
Feet
6
Inch
RISE 7
Feet
3-1/2
Inch
RISE AND DIAGONAL
Example: A right trangle has slope of 30˚ and length of 22 Feet 7 Inches. Find the height and diagonal.
KEY INPUT & DISPLAY
0
PTCH 30.00˚
RUN 22
Feet
7
Inch
RISE 13
Feet
0-7/16
Inch
DIAG 26
Feet
0-15/16
Inch
ANGLE AND DIAGONAL (HYPOTENUSE)
Example: A right trianagle measures 10 Feet high and 14 Feet long on each of its sides. Find the
diagonal (hypotenuse) of the traingle, and solve for the degree of angle (or pitch).
KEY INPUT & DISPLAY
0
RISE 10
Feet
0
Inch
RUN 14
Feet
0
Inch
1. Enter Rise and Run;
DIAG 17
Feet
2-7/16
Inch
PTCH 8-9/16
Inch
PTCH 35.54˚
2. Solve fo Diagonal/Hypotenuse and Pitch in Inches and Degree of Angle:
On/C On/C
Rise
Run
Feet
4
1 0
1
Feet
Pitch
Diag
Pitch
On/C On/C
Inch
Pitch
Rise
Run
Feet
Inch
7
6
1 2
On/C On/C
Pitch
Rise
Run
Diag
Feet
Inch
72
3
0
2
