Victor VC70D User Manual

Digital multimeter
17 / 25
mode can continue to test, and at this time “RANGE”.“MAX/MIN” “HOLD” re-ge t the controlling
Caution:
a） When measuring resistance, all the powers within the tested circuits must be disconnected and the
capacitance should be sufficiently discharged.
b） When measuring the resistance, any occurrence of voltage may lead to inaccurate readings, and if the
250V protection voltage is exceeded, it may damage the meter or threaten the safety of the user.
c） When using the range of 600Ω, first to short-circuit the testleads and measure the resistance of the
lead wire and then deduct it in the actual measurement.
Range
Accuracy
Resolution
600Ω
±(0.8%+5d)
0.1Ω
6kΩ
±(0.8%+4d)
1Ω
60kΩ
10Ω
600kΩ
100Ω
6MΩ
1kΩ
60MΩ
±(1.2%+10d)
10kΩ
Open circuit voltage: 600mV.
Overload protection: DC 250V or AC peak value.

Victor VC70D Specifications

General

Brand	Victor
Model	VC70D
Category	Multimeter
Language	English
