6.Specifications
BlueSolar PWM Charge
Controller
12V|24V|5A
12V|24V|10A
12V|24V|20A
12V
24V
12V
24V
12V
24V
Battery Voltage
12/24V Auto Select
Charge & Load Current
5A
10A
20A
Charge mode
PWM, Time and Lighting Control
Automatic load
disconnect
Yes
Maximum solar array
voltage
55V
Solar voltage range
15-28V [30-55V]
2
Self-consumption
<10mA
Protections
Reverse polarity connection of the solar panels.
Reverse polarity connection of the battery.
Low voltage disconnect.
130% load: Shuts down after 60sec.
160% load: Shuts down after 5sec.
Short circuit: immediate shut down.
Over-temperature protection.
Solar Panel
Recommended solar panel
array
36cell [72cell]
2
Max Solar Input Power
60W 120W 120W 240W 240W 480W
USB outputs
Voltage
5V
Current
2A (total from 2 USB outputs)
Default settings
Absorption charge
(b01)
1
14.4V [28.8V]
2
Float charge (b01)
1
13.7V [27.4V]
2
Load disconnect (b01)
1
11.2V [22.4V]
2
Load reconnect (b01)
1
12.6V [25.2V]
2
Enclosure
Terminal size
6mm² / AWG10
Weight
150gr
Dimension (h x w x d)
96 x 169 x 36 mm
Mounting
Vertical wall mount, indoor only
Humidity (non
condensing)
Max. 95%
Operating temperature
-35°C to +60°C (full load)
Cooling
Natural convection
Protection class
IP20
Standards
Safety
EN60335-1, IEC62109-1
EMC
EN61000-6-1, EN61000-6-3
1
See also 3.1 Battery type setting.
2
[V] values for 24V system.
