Pag. 3 MNVCPTH300_1541_EN
Identification data
On PTH310 / PTH311 pan & tilt motors there are two plates complying with EC specifications.
The first plate includes:
 Model identification code (Extended bar code 3/9 )
 Mains voltage (Volt)
 Frequency (Hertz)
 Power consumption (Watt)
The second plate shows the model serial number (Extended bar code 3/9)
When installing the appliance, check that the power supply specifications of the pan & tilt motor correspond to those
required. The use of improper appliances may seriously compromise the safety of the personnel and the installation.
Description of PTH310 / PTH311 pan & tilt motors
PTH310 / PTH311 unit is a vertical and horizontal pan & tilt motor, expressly projected for outdoor installations.
PTH310P / PTH311P models have all the features of PTH310 / PTH311 models, in addition to the PRESET.
Features
 Horizontal movement (Pan): from 0 to 330°. Speed: 6° per second
 Vertical movement (Tilt): from 0 to 360°. Speed: 3° per second
 Construction in corrosion-proof die-cast aluminium
 Completely sealed closing for indoor/outdoor operation
 Operating temperature from -23°C to +60°C (from -10°F to 140°F)
 PTH310 / PTH310P power supply: 230 V~
 PTH311 / PTH311P power supply: 24 V~
 PRESET for PTH310P / PTH311P models
 The Autopan function is possible for limited periods of time
Appliances compatible with PTH310 / PTH311
The working of pan & Tilt motors ist guarrated only if connected to:
 CBZ keyboard : Control keyboard for pan & tilt motors and zoom lenses
 DTRX3 receiver driver: 17-function digital receiver, allowing the remote control of pan & tilt motors, wiper and
wash, and 4 auxiliary contacts. It can be individually addressed up to 999 units. It allows the management of max.
14 preset positions, which are recalled in the switching cycle by the patrol function.
 DTMRX1 minireceiver driver: 11-function digital receiver, allowing the control of pan & tilt motors (horizontal and
vertical, zoom lenses, autopan). It can be individually addressed up to 64 units.
 MICRODEC control mini receiver: Current Loop digital receiver allows the basic control of a 24V~ pan & tilt
motor and the 12VDC polarity inversion zoom lenses. Individually addressable up to 32 units.
