4000 Series Vandal Resistant Digital GSM - Technical Manual
4000 Series Vandal Resistant Digital GSM Audio Intercom with Proximity
User Commands
USER COMMAND TABLES
The rst user table shows the user commands that can be carried out during a call. Successful commands are signalled by two beeps
from the telephone, errors are signalled by four beeps.
IMPORTANT NOTE: When the ED# function has been enabled the user must press the # button on their phone before pressing
any of the following user commands (also refer to page 56 for further information).
Table 1
FUNCTION 1st KEY TO PRESS 2nd KEY TO PRESS
Latch the relay (unlatch by pressing 3) 10
Release the door or gate 3 n/a
Activate auxiliary output AO
1
6 n/a
Adjust door speech volume (digital GSM speaker) 4 0 - 9 (0 = lowest, 9 = highest)
Adjust phone speech volume (digital GSM mic) 7 0 - 9 (0 = lowest, 9 = highest)
  Activating auxiliary output AO in this way is only possible when A1M mode has been set to mode 001 (also see notes on pages
13 and 51, ‘set auxiliary output AO mode’) and will operate for the programmed A1T time. If the AO output time has been set to
latch simply press 6 on the phone to unlatch the output again.
The second user table shows the SMS text messages that can be sent to the digital
GSM intercom while in standby (the examples shown in the table use the default 4
digit master code 1111). Successful text commands are signalled by a single beep from
the digital GSM and where the ? is used the appropriate conrmation text returned.
Unsuccessful text commands are signalled by a long beep followed by a short beep
from the digital GSM and where the ? is used the error message text returned, as
shown in Fig.115.
Fig. 115
Table 2
FUNCTION MESSAGE TO SEND
Check the signal strength 1111SIG?
Check the available balance
2
1111BAL?
Check the software version 1111VER?
Release the door/gate 1111RLY? (? optional, send if conrmation is required)
Latch the relay 1111RLA? (? optional, send if conrmation is required)
Unlatch the relay 1111RUL? (? optional, send if conrmation is required)
Activate auxiliary output AO 1111A1O? (? optional, send if conrmation is required)
Latch auxiliary output AO 1111A1L? (? optional, send if conrmation is required)
Unlatch auxiliary output AO 1111A1U? (? optional, send if conrmation is required)
Check Time band setting 1111TBAn? (where n = timeband 1 - 9)
Check Intercom Time and Date 1111CLK?
Find a Telephone number 1111FDT”yyyyyyyyyyy”? (where yyyyyyyyyyy = telephone number, minimum of 4
digits, also refer to pages 58 and 59)
Find a Fob or Card location 1111FDF”nnnnn”? (where nnnnn = 5 digit user code printed on fob/card, also refer
to page 59)
  The balance can only be checked if the correct balance check string has been stored (also see SDL notes on page 53).
