4000 Series GSM Audio Intercom - Technical Manual
4000 Series GSM Audio Intercom with Proximity
Programming the GSM Intercom
PROGRAMMING THE GSM INTERCOM
Programming the GSM PRO intercom can be carried out in two ways, either by sending text (SMS) messages or by using the GSMSK
PC software (ver 3.0.0.2 or later).
IMPORTANT NOTE: When you are required to use “ in a text message it is very important to use the correct symbol and not for
example ‘ (or two ‘ single apostrophes side by side which you will see look the same but will be interpreted dierently by the
GSM PRO intercom panel).
PROGRAMMING BY TEXT MESSAGE
Programming by text message is a simple way to customise the settings of the GSM PRO intercom panel and add or delete telephone
numbers. If you have a large number of buttons or telephone numbers to enter you may nd programming easier with the GSMSK
PC software. Simply send texts in the following format shown below to the telephone number of the SIM within the GSM PRO
intercom panel:
<4 DIGIT CODE> <3 DIGIT FUNCTION CODE> <OPTIONAL DATA> <OPTIONAL ?>
4 DIGIT CODE This code prevents unauthorised access to the programmable features of the system. The code
must be four digits long but can be any combination using digits 0 – 9. The default code is 1111
and will be used for all examples in this manual.
3 DIGIT FUNCTION CODE The 3 digit function code identies the programmable feature to be changed. The code must
be in capital letters. The following table lists the available codes.
DESCRIPTION CODE EXAMPLE SETTINGS DEFAULT PAGE
Store a primary telephone no. STN 1111STNnnn”01912243174” nnn = 001 - 050 n/a 33 - 34
Store divert 1 telephone no. STD 1111STDnnn”01912241559” nnn = 001 - 050 n/a 33 - 34
Store divert 2 telephone no. STE 1111STEnnn”01912243678” nnn = 001 - 050 n/a 33 - 34
Store divert 3 telephone no. STF 1111STFnnn”01912245326” nnn = 001 - 050 n/a 33 - 34
Store dial to open no. STR 1111STRnnn”07771234567” nnn = 000 - 999 n/a 34
Set call time SPT 1111SPTnn nn = 01 - 12 02 (40s) 34
Set relay time RLT 1111RLTnn nn = 00 - 99 05 (5s) 34
Set auxiliary AO1 output time A1T 1111A1Tnn nn = 00 - 99 05 (5s) 35
Set auxiliary AO1 out mode A1M 1111A1Mnn nn = 00 - 05 01 35
Set auxiliary AO2 output time A2T 1111A2Tnn nn = 00 - 99 05 (5s) 35
Keep connection facility NOD 1111NODnn nn = 01 - 99 0 (disabled) 35 - 36
Divert to next no. time DIT 1111DITnn nn = 01 - 99 15 (15s) 36
Check GSM signal strength SIG 1111SIG? n/a n/a 36
Check software version VER 1111VER? n/a n/a 36
Dial a number DLE 1111DLE”123” n/a n/a 36
Store SMS message for g-4 SMS 1111SMS”HouseAlarm” n/a AUX TRIG 36
Change 4 digit code CDE 1111CDE1234 Any 4 digits 1111 37
Trigger the relay RLY 1111RLY n/a n/a 37
Trigger the auxiliary output AO1 A1O 1111A1O n/a n/a 37
Trigger the auxiliary output AO2 A2O 1111A2O n/a n/a 37
Store balance check dial string SDL 1111SDL”*#1345#” n/a n/a 37
Check credit balance BAL 1111BAL? n/a n/a 37 - 38
Store master telephone no. STM 1111STM”07771234567” n/a n/a 38
Latch the relay RLA 1111RLA n/a n/a 38
Unlatch the relay RUL 1111RUL n/a n/a 38
Latch the auxiliary AO1 output A1L 1111A1L n/a n/a 38
Unlatch the auxiliary AO1 output A1U 1111A1U n/a n/a 38
Latch the auxiliary AO2 output A2L 1111A2L n/a n/a 38
Unlatch the auxiliary AO2 output A2U 1111A2U n/a n/a 39
