4000 Series GSM Audio Intercom - Technical Manual
4000 Series GSM Audio Intercom with Proximity
System Operation
MAKING A CALL FROM THE GSM INTERCOM
Press the required call button. Two beeps will be heard to
indicate the call has been placed (see Fig.56). The busy
LED will illuminate and the call LED will ash to indicate
that the system is engaged and a call is in progress (see
Fig.57).
If a mistake is made, press any other button to clear the call
(see Fig.58). A long beep followed by a short beep will be
heard to conrm the call has been cleared. Both the busy
and call LEDs will switch OFF (see Fig.59).
IMPORTANT NOTE: If the same button is pressed again
after ve seconds of placing the initial call this will also
clear the call down. Pressing the same button before the
ve seconds is up will do nothing.
Fig. 56 Fig. 57
Fig. 58 Fig. 59
DOOR/GATE RELEASE
This is signalled by 1 second interval beeps from the GSM PRO intercom panel. Pressing 3 on the phone releases the door/gate for
the programmed time. Pressing 1 followed by 0 will latch the door/gate in the open position (to unlatch press 3 and the door/gate
will unlatch after the programmed time or send the SMS text message 1111RUL, also refer to page 38).
RELEASING THE DOOR/GATE BY DIALLING THE GSM PRO INTERCOM DIAL IN DOOR RELEASE STR
This feature is only possible if the caller’s number has been stored correctly for this feature (also refer to page 34 for correct setup).
Simply dial the number of the GSM PRO intercom panel. The intercom panel will drop the call and then open the gate/door for the
programmed time.
B
e
e
p
!
B
e
e
p
!
House 1
House 2
B
e
e
e
e
e
p
!
B
e
e
p
!
House 1
House 2
