PAGE 4 of 80 VX2200 TECHNICAL MANUAL VER1.4
MANUAL INTRODUCTION
The information in this manual is intended as an installation and commissioning guide for the VX2200 Digital
system. This manual should be read carefully before the installation commences. Any damage caused to the
equipment due to faulty installations where the information in this manual has not been followed is not the
responsibility of Videx Security Ltd.
VIDEX run free training courses for engineers who are not familiar with the Videx product range. Technical
help is also available on 0191 224 3174 during office hours or via e-mail tech@videx-security.com
.
SYSTEM INTRODUCTION
The VX2200 audio system is based on a “2 wire” BUS for audio systems and a “6 wire” bus for video
systems. The system meets all the requirements of a small to medium sized installation.
The digital front panels are available in several versions including the 800 series design (With either
alphanumeric A-H feature or Name scroll feature), 4000 series design (With either alphanumeric A-H feature
or Name scroll feature) and vandal resistant with optional alpha buttons A-H. All digital panels have the
facility to call up to 998 users when using 2206N bus exchange devices (180 per block, 150 with 900 Series
or 255 for versions combined with 316x telephones), each user has the additional feature of a personal
access code to gain access to the building. Functional panels are also available with up to 64 buttons. All
intercom telephones are addressed by means of an 8 way dip-switch located within each handset.
SYSTEM COMPONENTS
800 Series Digital Front Panels (2202M, 2202MR)
These units are built into a double 800 series module (stainless steel/S or aluminium/A) and have a 2 line16
character LCD display, speaker unit and numeric keypad with either 8 alpha buttons [A-H] (VX2202/2202M)
or 3 scroll buttons (VX2202R/2202MR) to navigate the “Repertory Names”. A PC based programming kit is
also available (SP37) which includes software and serial cable to simplify the programming of large
installations.
Vandal resistant Digital Front Panels (SP300, SP301)
These units are based on the 800 series module electronics and have a 2 line 16 character LCD display,
speaker unit and numeric keypad, and 12 gauge stainless steel facia with bezel back box.
4000 Series Digital Front Panels (4202, 4202R, 4202V, 4202RV)
The 4000 Series door panels have the same features as the 800 series version but are based on the 4000
series modular system and can also include mono or colour video within the two module design. Versions
with either alpha buttons [A-F] or scroll buttons are available and include a high contrast blue back lit 2 line
16 character LCD display. The face plate is available in either mirror finish stainless steel (standard version)
or matt finish anodized aluminium).
Digital panels features:
- Call up to 998 users (Version 5.0 software or later) (only 150 with 900 Series telephone);
- Call up to 255 users when using 316x telephones;
- Open the door by means of an individual personal access code
- Enter the “programming menu” (by using a programmable master code), where it is possible to assign:
a. Trade access code for periodic visitors such as postman etc
b. one or more apartment numbers for each telephone
c. one or more individual access codes (up to 6 digits)
d. User name (Scroll facility door panels only)
e. the device number for each outdoor station
f. Choose from six languages
g. speech play back system
h. speech time and door opening time (up to 255 seconds);
i. Automatic test mode
- Connect up to 10 entrance panels (main or secondary). An installation can consist of main entrances (Which can call all users) and
block entrances (Which can only call users in these blocks). On two level systems of this type a VX2206 bus exchange device is
needed per block.
The LCD display will show all relevant information during the call procedure along with acoustic signals and
voice annunciation.
800 Series Functional module (2203-0, 2203-1, 2203-2)
Built into a single 800 series module and includes the speaker unit and interfaces to the digital bus. Up to 64
push buttons can be added to the interface using the 843, 844, 845 expansion button modules. (The 2203 is
available with either 1 button, 2 buttons or no buttons).
4000 Series Functional Module (4203-0, 4203-1, 4203-2, 4203-1D, 4203-2D)
Built into a single 4000 series module and includes the speaker unit plus 4 LED’s to provide call progress
To Next Page
