Cutter Cover Install—020811 pg. 7
Cutting Bar—Cutter Cover Installation
Cutter Cover Installation
The following instructions will describe the process of installing the cutter cover on
your cutting bar. Please follow the instructions carefully to ensure proper installation.
Kit Includes: Cutter Cover, Set Screws (4), Hex Spacer (4)
Tools Required: 9/16” Wrench, 1/8” Allen Wrench
1. Crank the cutter to a position where you can access it to install the cutter cover.
BE SURE HANDS ARE CLEAR OF THE TRACK.
2. Remove wing nuts from the wheels of your cutter. (Some cutters may have plain
nuts instead of wing nuts)
