Page 20 of 72 PYROMAT DYN45 - DYN85 Issue 1.0 5726 783
5 Operation
5.1 Basic menu navigation - ECOTRONIC
The ECOTRONIC controller gathers all data relevant for operations and regulates the
heat output and heat consumption.
The boiler system is continuously monitored in all phases of operation and is kept in the
optimised emissions zone.
Fig. 4 ECOTRONIC overview
A
Display
B
Navigation buttons
C
Increase/decrease parameter,
confirm input
D
Function keys with built-in LEDs:
Selection of the various menus.
