Page 44 of 72 PYROMAT DYN45 - DYN85 Issue 1.0 5726 783
6.3 Air heating apparatus
Function ECO-L
The air heaters are supplied with the maximum supply temperature by the boiler
storage system. The blowers are controlled by the customer's on-site switches or
controllers.
The hot water flow rate is controlled by the return flow temperature (flow control) and
this in turn adapts the heat output of the air heater.
This results in an optimised storage stratification with a higher temperature maintained
in the storage feed over a longer period. The heating times (day and week program)
can be adjusted via the integrated timer.
Adjustable parameters
Screen
number
Parameters Factory setting
01 Operating mode:
Operating mode selection.
Off
Air heater is switched off.
Day / Off
The air heater is controlled in accordance
with a timer program. By day controlled with
return flow target value, by night air heater is
switched off.
Day
The boiler is heated up when there is a
demand for heat and when the system
temperature is sufficient:
Manual
The pump is switched on, the valve is not
controlled.
L Use this setting only for emergency
operation if a fault message is shown on the
display.
1. Inform your heating specialists for further
instructions on fault rectification.
Day / Off
02 Number of heating periods:
The week program is entered in the form of
heating periods. Each week program comprises
heating days, start and end.
There are a maximum of 7 heating periods
available.
1
03 Heating period 1, heating day:
Day or days for which the switching times are to
be applied. The heating days are selected with
keys F1 (for Monday) to F7 (for Sunday).
One button press Æ day selected, one further
button press Æ day deselected.
L This setting is only available in day / off
operating mode.
Mon to Sun
04 Heating period 1, start:
Set switch-on time for the air heater.
This setting is only available in day / off
operating mode.
06:00
