Page 66 of 72 PYROMAT DYN45 - DYN85 Issue 1.0 5726 783
8.3.2 Loading
No. Error report display Error sensor Possible cause Check, rectification
01 Shortage of material
Function key F4
illuminates red.
 Light barrier in dosing container
 Light barriers for ember
monitoring system
 Silo is empty
 Material blockage
1. Fill silo.
2. Switch off main switch and clear material
blockage.
3. Cancel error with OK.
11
to
24
Starttec …
Function key F4
illuminates red.
 Starttec (motor starter built onto
the motor terminal board)
 Red lamp on Starttec illuminates
 Phase sequence swapped
 Motor overloaded
 Further causes depending on error
reports on display.
1. Set phase sequence correctly (clockwise
phase sequence).
2. Clear obstruction, ensure motor moves freely -
see Starttec documentation.
3. Cancel error with OK.
30 Feed auger
Function key F4
illuminates red.
 Feed auger reversing controller  Material blockage in the feed auger 1. Clear material blockage.
31
to
45
Feed system ...
Function key F4
illuminates red.
 Maintenance cover - limit switch  One of the maintenance covers is
open or not completely closed.
1. Check and close all maintenance covers.
2. Cancel error with OK.
51
to
52
Extraction ...
Function key F4
illuminates red.
 Maintenance cover - limit switch  One of the maintenance covers is
open or not completely closed.
1. Check and close all maintenance covers.
2. Cancel error with OK.
53
to
54
Extraction ... hydraulic
drive, temperature /
level
Function key F4
illuminates red.
 Level float switch in sliding bar
extractor oil
reservoir.
 Thermostat in oil reservoir
 Oil level too low (possible loss of oil)
 Oil was overheated through excess
pressure.
1. Refill oil - check leak-tightness of oil lines
2. Check and adjust operating pressure (by Köb)
3. Cancel error with OK.
Extraction ... Silo door
open
Function key F4
illuminates red.
 Limit switch silo door  Silo door open 1. Check and close silo door.
2. Cancel error with OK.
