Data sheet
Burner System Loader System
PYROMAT-DYN
1
Köb Holzheizsysteme GmbH, Flotzbachstr. 33, A-6922 Wolfurt, Tel. +43/5574/6770-0, Fax 65707, E-Mail: office@kob.cc
Subject to technical changes
3010-5
2009-03-01_GB
Table of dimensions:
Pyromat-DYN [Art. No.] KPM-DYN_45 KPM-DYN_65 KPM-DYN_85
I Forward flow, connection Bsp R 1¼“ R 1¼“ R 1½“
II Return flow, connection Bsp R 1¼“ R 1¼“ R 1½“
III Safety valve connection Bsp R ½“ R ½“ R ½“
IV
Sensor for run-off safety valve
connection Bsp
R ½“ R ½“ R ½“
V Drain valve R ½“ R ½“ R ½“
VI Inspection window (transport hook) connection Bsp R 1“ R 1“ R 1“
A Height of casing 1430 1490 1490
B Width of casing (dismantled) 795 (686) 795 (686) 795 (686)
C Length of casing 958 1163 1313
D Length of exhaust fan 500 500 630
E Filling height 1134 1134 1134
F Height of lid, open 1892 2012 2012
G Radius of ash door 365 365 365
H Outlet, burner 265 265 265
J Outlet, exhaust fan 175 175 300
M Flange, forward flow, burner 1331 1389 1386
N Flange, return flow, burner 811 869 693
O Space for operation 800 800 800
P Min. distance to wall 100 100 100
S Connection for exhaust fan 1) 200 200 200
T Width of firebox 550 550 550
U Depth of firebox 300 400 400
W Outlet, exhaust fan 293 293 293
Z Slide-in module flange 650 765 800
a Connection, burner 108 108 108
b Connection, burner 214 214 214
c Connection, burner 183 183 183
Operation and maintenance
1 Firebox door
2 Ash pan door
3 Cleaning door, top
4 Cleaning door, bottom (slide-in module side)
5 Maintenance lid to radiation chamber
6 Maintenance lid to combustion chamber, automatic (opposite slide-in module)
Electric drives, burner [Art. No. KPM-DYN-..]
10 Drive, de-ashing / Cleaning (opposite slide-in module)
11 Motor-driven air vent (primary and secondary)
12 Motor for exhaust fan
13 Burner pump
14 Burner control valve with servomotor
Electric connections and sensors, burner
21 Burner sensor
22 Return flow sensor
23 Exhaust gas sensor
24 Lambda sensor
25 Burner control panel with temperature-limiting safety switch
26 Sockets for electrical connection
Electric drives and sensors, slide-in module
31 Drive for feed auger
32 Light barrier for metering container
33 Light barrier for combustion chamber
34 Temperature sensor for feed auger
35 Ignition device
1
) Reduction up to KPM-DYN-65 is possible (160 mm or 180 mm)
