Viessmann Vitocal 252-A Series - Page 156

156
When fitting the right side panel, make sure it is positioned correctly:
6x
!
2.
1.
2x
Fig. 105
Note
Torque for the nuts: 1.5 +1.0 Nm
Removing the top casing
1. Remove side casing, right: See Fig. 104.
Outdoor unit maintenance
Removing the outer casing (cont.)
6222080
Maintenance
