99
3. Start commissioning on the heat pump (main
appliance):
Launch the commissioning process on the heat
pump via the commissioning assistant:
■
If the heat pump hasn't been switched on yet, the
commissioning assistant starts automatically.
■
If the heat pump has already been switched on:
See chapter "Calling up the commissioning
assistant at a later point".
Select "Commissioning with software tool":
■
The heat pump automatically activates the
access point. A direct WiFi connection to a
mobile device is established via the access point.
This WiFi connection is independent of the home
WiFi network.
■
The other connected Viessmann appliances
detect the connection to the heat pump (main
appliance). Some Viessmann appliances indicate
on the HMI programming unit display that con-
nection was successful.
4. Commission and set up the system network:
Start the ViGuide app on the mobile device. Follow
the instructions.
■
Scan the QR code on the label.
Or
■
Enter the name of the access point
"Viessmann-xxxx" and the password ("WPA2").
Commission all Viessmann appliances via the heat
pump's access point using the ViGuide app.
Perform all necessary settings in the ViGuide app.
5. Further settings via the ViCare app:
The heat pump must be connected to the
Viessmann server via the internet in order to per-
form settings via the ViCare app. This internet con-
nection is established via the home WiFi.
To set up the internet connection:
Operating instructions
Setting up the internet connection
For maintenance and service via ViGuide and for oper-
ation via the ViCare app, an internet connection
between the heat pump and the Viessmann server is
required.
To set up the internet connection:
Operating instructions
Calling up the commissioning assistant at a later point
If you need to continue commissioning later, the com-
missioning assistant can be restarted at any time.
Tap the following buttons:
1.
2. "Service"
3. Enter password "viservice".
4. Confirm with .
5. "Commissioning"
Commissioning assistant
Procedure Explanations and references
Commissioning
Language Select the required menu language for the programming unit.
Commissioning tool
■
With programming unit
(HMI)
Commissioning is continued with the programming unit.
■
Commissioning with
software tool
The access point of the heat pump is switched on automatically. For the next
commissioning steps, follow the instructions in ViGuide.
Demo operation In demo operation, sensor values and hydraulic settings are simulated. The acti-
vated demo mode can be terminated from the Service menu. Upon return to nor-
mal operation, a restart is carried out.
Commissioning, inspection, maintenance
Commissioning the system (cont.)
6222080
