157
2.
3.
D
B
C
A
TX 25
4.
!
Fig. 106
Note
Torque for both screws: 1.8 +0.5 Nm
A
Cover
B
Air space cover
C
EPP support
D
Cover with gasket and sound insulation
Outdoor unit maintenance
Removing the outer casing (cont.)
6222080
Maintenance
