158
Removing the front casing
C
B
A
2.
1.
3.
TX 25
Fig. 107
Note
Torque for the screws: 1.8 +0.5 Nm
A
Only for outdoor unit with 2 fans:
Upper fan grille
B
Reinforcing strut
C
Lower fan grille
Outdoor unit maintenance
Removing the outer casing (cont.)
6222080
Maintenance
