94
Note
The following information for closing the outdoor unit
applies to outdoor units with 1 or 2 fans. The outdoor
unit with 2 fans is shown as an example.
6x
!
2.
1.
2x
Fig. 71
2. Torque 1.5 +1.0 Nm
Electrical connections
Closing the outdoor unit
6222080
Installation
