Viessmann VITOCELL 100-W - Fitting the Thermal Insulation, Type SVP; Fitting the Lower Thermal Insulation Mat; Fitting the Thermal Insulation Jacket

12
Fitting the lower thermal insulation mat
2.
1.
Fig. 8
!
Please note
The thermal insulation must not come into con-
tact with naked flames.
Exercise caution when welding and brazing.
Fitting the thermal insulation jacket
Note
Ensure that no fleece remnants enter the heating
water buffer cylinder through the cylinder connections.
Installation sequence
Fitting the thermal insulation, type SVP
5517 175 GB
Installation
