Fitting the lower thermal insulation mat, aligning the Vitocell
A
B
3.
3x
1.
4.
2.
Fig. 12
A
Type plate
B
Bag with adjustable feet
Insert the adjustable feet into the legs as far as possi-
ble, then adjust them to level the cylinder.
Note
Never extend the adjustable feet beyond a total length
of 35 mm.
Installation sequence
Fitting the Vitotrans and thermal insulation,… (cont.)
5517 175 GB
Installation
