Fitting the Vitotrans
1.
2.
Fig. 14
2.
3.
1.
Fig. 15
1. Fit the bolts to the cylinder.
2. Fit the module.
3. Wind the nuts onto the bolts until hand-tight.
Installation sequence
Fitting the Vitotrans and thermal insulation,… (cont.)
