29
Pos. Component Serial no. (see type plate)
7201937 7201938
Part no. of individual part
0001 Adjustable foot 7825600 7825600
0002 Sensor retainer 7819654 7819654
0003 Vitocell 100-E SVPA type plate 5848673 5848674
0004 Clamping bracket 7819655 7819655
0005 Vitocell 100-E installation and service instructions 5583599 5583599
0006 Plug 7843297 7843297
0006
0005
0003
0004
0002
0001
Fig. 25
Thermal insulation assembly
Pos. Component Serial no. (see type plate)
7201937 7201938
Part no. of individual part
0001 Clip fastener (6 pce) 7835643 7835643
0002 Thermal insulation jacket 100-E, right 7843102 7843104
Parts list, type SVPA (750/950 l)
Cylinder assembly
5517 175 GB
Service
