52
3-way diverter valve in sub-mounting kit
4 3 2 J 4 3 2 M 4 3 2 F 4 3 2 Z
LNPEL LNPE
X200
A
B
EX2 EX1
QX3
QX4
QX2
A
3-way diverter valve
B
Plug on plug-in strip X200 in the
control unit
Connection to the control unit
See separate installation instruc-
tions.
Installation sequence
Terminal connections
(cont.)
5618 294 GB
