ViewSonic PJD5112 User Manual

EN-32
RS-232 Command and Configuration
Baud Rate:19200 Parity Bit:none
Data Bit:8 Stop Bit:1 Assign Port:COM1
Name
Operation
type
CRC
Header Command Response
Power
ON BE, EF, 10, 05, 00, C6, FF, 11, 11, 01, 00, 01, 00 06
OFF BE, EF, 03, 06, 00, DC, DB, 69, 00, 00, 00, 00, 00 06
Source
Computer
(Analog RGB) BE, EF, 03, 19, 00, 19, 29, 01, 47, 02, CC, CC, 00 06
YCbCr BE, EF, 03, 19, 00, 89, E8, 01, 47, 02, CC, CC, 00 06
S-Video BE, EF, 03, 19, 00, E8, 69, 01, 47, 02, CC, CC, 00 06
Composite
Video
BE, EF, 03, 19, 00, 78, A8, 01, 47, 02, CC, CC, 00 06
HDTV (Y-Pb-
Pr)
BE, EF, 03, 19, 00, DA, 2B, 01, 47, 02, CC, CC, 00 06
OSD
Menu BE, EF, 02, 06, 00, E9, D3, 30, 00, 00, 00, 00, 00 06
Up BE, EF, 02, 06, 00, 6D, D2, 34, 00, 00, 00, 00, 00 06
Down BE, EF, 02, 06, 00, 0B, D2, 32, 00, 00, 00, 00, 00 06
Left BE, EF, 02, 06, 00, DA, D3, 33, 00, 00, 00, 00, 00 06
Right BE, EF, 02, 06, 00, 38, D2, 31, 00, 00, 00, 00, 00 06
ECO On BE, EF, 03, 06, 00, EF, DB, 6A, 00, 00, 00, 00, 00 06
Off BE, EF, 03, 06, 00, 3E, DA, 6B, 00, 00, 00, 00, 00 06
Auto
Source
On BE, EF, 03, 06, 00, 89, DB, 6C, 00, 00, 00, 00, 00 06
Off BE, EF, 03, 06, 00, 58, DA, 6D, 00, 00, 00, 00, 00 06
Source BE, EF, 02, 06, 00, 57, D0, 2E, 00, 00, 00, 00, 00 06
Auto-Sync BE, EF, 02, 06, 00, 86, D1, 2F, 00, 00, 00, 00, 00 06
Blank Screen(Video) BE, EF, 02, 06, 00, DF, DF, 66, 00, 00, 00, 00, 00 06
Keystone
Keystone BE, EF, 02, 06, 00, 3D, DE, 64, 00, 00, 00, 00, 00 06
Up BE, EF, 03, 06, 00, 10, DB, 65, 00, 00, 00, 00, 00 06
Down BE, EF, 03, 06, 00, 23, DB, 66, 00, 00, 00, 00, 00 06
Image BE, EF, 03, 06, 00, F2, DA, 67, 00, 00, 00, 00, 00 06
Aspect Ratio BE, EF, 03, 06, 00, 0D, DA, 68, 00, 00, 00, 00, 00 06
Factory Reset BE, EF, 03, 06, 00, 6B, DA, 6E, 00, 00, 00, 00, 00 06
Lamp Hour BE, EF, 03, 06, 00, BA, DB, 6F, 00, 00, 00, 00, 00 Lamp Hour
Firmware Version BE, EF, 03, 06, 00, D5, D9, 70, 00, 00, 00, 00, 00 Version
System Status BE, EF, 03, 06, 00, 04, D8, 71, 00, 00, 00, 00, 00 03:Projector
ON
(Normal
Mode)

ViewSonic PJD5112 Specifications

General

Projection distance	1.2 - 10 m
Projection technology	DLP
Contrast ratio (typical)	2000:1
Projector native resolution	SVGA (800x600)
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	280 x 218 x 114 mm
Power requirements	90~240VAC
Lamp power	180 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	5000 h
Focus	Manual
RMS rated power	2 W
Headphone outputs	2
Serial interface type	RS-232
Noise level	30 dB
Power consumption (standby)	1 W
Power consumption (typical)	235 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product type	Standard throw projector
Market positioning	Presentation

Weight and Dimensions

Weight	2600 g
