Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
Important
In the connections shown above, some cables may not be included with the
projector (see “Package Contents” on page 6). They are commercially
available from electronics stores.
The connection illustrations above are for reference only. The rear
connecting jacks available on the projector vary with each projector model.
For detailed connection methods, see pages 16-19.
Audio cable VGA cable (D-Sub to D-Sub)
Composite Video cable USB cable
S-Video cable VGA to DVI-A cable
VGA (D-Sub) to HDTV (RCA) cable
2 3
4
1
5 6
5
7
1 1
To Next Page
