ViewSonic PJD5123 User Manual

EN-41
41
RS-232 Command and Configuration
Function Action Control Code Return
Code
Power Power on BE,EF,10,05,00,C6,FF,11,11,01,00,01,00 6
Power off BE,EF,03,06,00,DC,DB,69,00,00,00,00,00 6
Source input Computer1 BE,EF,03,19,00,19,29,01,47,02,CC,CC,00 6
Computer2 BE,EF,03,19,1E,90,72,01,47,02,CC,CC,00 6
S-Video BE,EF,03,19,00,E8,69,01,47,02,CC,CC,00 6
Video BE,EF,03,19,00,78,A8,01,47,02,CC,CC,00 6
Projector
position
Front table BE,EF,10,07,9F,9D,0E,0A,EF,00,00,00,00 6
Rear table BE,EF,10,07,9F,9D,0E,0A,EF,01,00,00,01 6
Front ceiling BE,EF,10,07,9F,9D,0E,0A,EF,02,00,00,02 6
Rear ceiling BE,EF,10,07,9F,9D,0E,0A,EF,03,00,00,03 6
OSD Menu BE,EF,02,06,00,E9,D3,30,00,00,00,00,00 6
Up BE,EF,02,06,00,6D,D2,34,00,00,00,00,00 6
Down BE,EF,02,06,00,0B,D2,32,00,00,00,00,00 6
Left BE,EF,02,06,00,DA,D3,33,00,00,00,00,00 6
Right BE,EF,02,06,00,38,D2,31,00,00,00,00,00 6
Lamp ECO on BE,EF,03,06,00,EF,DB,6A,00,00,00,00,00 6
ECO off BE,EF,03,06,00,3E,DA,6B,00,00,00,00,00 6
Using hours BE,EF,03,06,00,BA,DB,6F,00,00,00,00,00 xxxx
Fan High Attitude on BE,EF,02,06,00,40,D3,80,00,00,00,00,01 6
High Attitude off BE,EF,02,06,00,40,D3,80,00,00,00,00,00 6
Keystone Keystone up BE,EF,03,06,00,10,DB,65,00,00,00,00,00 6
Keystone down BE,EF,03,06,00,23,DB,66,00,00,00,00,00 6
Aspect ratio 4:3 BE,EF,03,06,00,0D,DA,68,00,01,00,00,01 6
16:9 BE,EF,03,06,00,0D,DA,68,00,02,00,00,02 6
Blank Blank on BE,EF,02,06,00,DF,DF,66,00,01,00,00,01 6
Blank off BE,EF,02,06,00,DF,DF,66,00,02,00,00,02 6
Freeze Freeze on BE,EF,02,06,00,02,D0,2B,00,01,00,00,01 6
Freeze off BE,EF,02,06,00,02,D0,2B,00,02,00,00,02 6
Volume Volume + BE,EF,02,06,00,F1,DE,68,00,00,00,00,00 6
Volume - BE,EF,02,06,00,20,DF,69,00,00,00,00,00 6
Mute on BE,EF,02,06,00,0E,DE,67,00,01,00,00,01 6
Mute off BE,EF,02,06,00,0E,DE,67,00,02,00,00,02 6
Auto source Auto source on BE,EF,03,06,00,89,DB,6C,00,00,00,00,00 6
Auto source off BE,EF,03,06,00,58,DA,6D,00,00,00,00,00 6
Auto Sync BE,EF,03,06,00,58,DA,6D,00,00,00,00,00 6
Factory
default
BE,EF,03,06,00,6B,DA,6E,00,00,00,00,00 6

ViewSonic PJD5123 Specifications

General

Matrix size	0.55 \
Number of colors	16.78 million colors
Projection distance	1.2 - 11 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	31 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Digital gamma correction	Yes
Screen size compatibility	27 - 300 \
Projector native resolution	SVGA (800x600)
Audio input	1
Aspect ratio	16:10
Compatibility	- PC VGA & UXGA - Mac 1600×1200 & 60Hz
Dimensions (WxDxH)	284 x 234 x 82 mm
Focal length range	- mm
Lamp power	180 W
Light source type	Lamp
Service life of light source	6000 h
DVI port	No
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	2
Analog signal format system	PAL B, PAL D, PAL G, PAL H, PAL I, SECAM D/K
RMS rated power	1 W
Product color	Black
Market positioning	Presentation
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	235 W
Noise level	32 dB
Certification	RoHS, CB, CCC, PSB, C-tick, KC, SASO, CE, GOST-R, Ukr, ErP, SVHC list & REACH DoC, UL, FCC (& ICES-003), cUL/ CSA, Argen, NOM
Noise level (economic mode)	30 dB
Operating altitude	0 - 3048 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, VGA

Weight and Dimensions

Weight	2600 g
Package weight	3400 g
