ViewSonic PJD5123 User Manual

EN-19
19
details.
Connecting a composite Video source device
Examine your Video source device to determine if it has a set of unused composite
Video output sockets available:
 If so, you can continue with this procedure.
 If not, you will need to reassess which method you can use to connect to the
device.
To connect the projector to a composite Video source device:
1. Take a Video cable and connect one end to the composite Video output socket of
the Video source device.
2. Connect the other end of the Video cable to the VIDEO socket on the projector.
Important
 If the selected video image is not displayed after the projector is turned on
and the correct video source has been selected, check that the Video source
device is turned on and operating correctly. Also check that the signal cables
have been connected correctly.
 You need only connect to this device using a composite Video connection if
Component Video and S-Video inputs are unavailable for use. See
“Connecting Video source devices” on page 17 for details.

ViewSonic PJD5123 Specifications

General

Matrix size	0.55 \
Number of colors	16.78 million colors
Projection distance	1.2 - 11 m
Vertical scan range	50 - 120 Hz
Horizontal scan range	31 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Digital gamma correction	Yes
Screen size compatibility	27 - 300 \
Projector native resolution	SVGA (800x600)
Audio input	1
Aspect ratio	16:10
Compatibility	- PC VGA & UXGA - Mac 1600×1200 & 60Hz
Dimensions (WxDxH)	284 x 234 x 82 mm
Focal length range	- mm
Lamp power	180 W
Light source type	Lamp
Service life of light source	6000 h
DVI port	No
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	2
Analog signal format system	PAL B, PAL D, PAL G, PAL H, PAL I, SECAM D/K
RMS rated power	1 W
Product color	Black
Market positioning	Presentation
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	235 W
Noise level	32 dB
Certification	RoHS, CB, CCC, PSB, C-tick, KC, SASO, CE, GOST-R, Ukr, ErP, SVHC list & REACH DoC, UL, FCC (& ICES-003), cUL/ CSA, Argen, NOM
Noise level (economic mode)	30 dB
Operating altitude	0 - 3048 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	AC, VGA

Weight and Dimensions

Weight	2600 g
Package weight	3400 g
