ViewSonic PLED-W500 User Manual

iv
Copyright Information
Copyright © ViewSonic
®
Corporation, 2012. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft
Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks
of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association. DPMS and
DDC are trademarks of VESA.
PS/2, VGA and XGA are registered trademarks of International Business Machines Corporation.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omis-
sions contained herein; nor for incidental or consequential damages resulting from furnishing
this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
FKDQJHSURGXFWVSHFL¿FDWLRQVZLWKRXWQRWLFH,QIRUPDWLRQLQWKLVGRFXPHQWPD\FKDQJHZLWKRXW
notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any
purpose without prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic
®
Wizard CD-ROM also provides an opportunity for you to print the registration form, which you
may mail or fax to ViewSonic.
For Your Records
Product Name: PLED-W500
ViewSonic LED Projector
Model Number: VS14048
Document Number: PLED-W500_UG_ENG Rev. 1B 03-22-12
Serial Number: _______________________________
Purchase Date: _______________________________
Product disposal at end of product life
The lamp in this product contains mercury which can be dangerous to you and the environment.
Please use care and dispose of in accordance with local, state or federal laws.
ViewSonic respects the environment and is committed to working and living green. Thank you
for being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/kbase/article.php?id=639
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx

ViewSonic PLED-W500 Specifications

General

Matrix size	0.45 \
Number of colors	16.78 million colors
Projection distance	0.91 - 2.4 m
Vertical scan range	48 - 120 Hz
Horizontal scan range	31 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	6000:1
Screen size compatibility	30 - 80 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-40 - 40 °
Aspect ratio	16:10
RS-232 ports	-
Network ready	No
Dimensions (WxDxH)	214 x 164 x 42 mm
Connectivity technology	Wired
Maximum analog resolution	1680 x 1050 pixels
Maximum digital resolution	1920 x 1080 pixels
Focus	Manual
Focal length range	- mm
Lamps quantity	1 lamp(s)
Light source type	LED
Service life of light source	20000 h
PC Audio in	Yes
USB connector type	USB Type-A
USB 2.0 ports quantity	2
S-Video inputs quantity	1
Ethernet LAN (RJ-45) ports	0
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1440 x 1050, 1680 x 1050 (WSXGA+), 640 x 480 (VGA)
RMS rated power	2 W
Audio formats supported	MP3
Video formats supported	H.264, MPEG2, MPEG4
Product color	Black
Market positioning	Portable
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	144 W
Compatible memory cards	SD
Internal storage capacity	0.5 GB
Noise level	38 dB
Certification	CE, CB, UL, cUL, FCC (including ICES-003), NOM, TUV-S Argentina, RoHS
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	VGA

Weight and Dimensions

Weight	1180 g
