ViewSonic PLED-W500 User Manual

6
Table of Contents
Introduction 7
Package Overview ................................. 7
Product Overview ................................... 8
Main Unit............................................ 8
Control Panel ..................................... 9
Connection Ports ............................. 10
Remote Control.................................11
Installation 12
Connecting to Computer/Notebook ...... 12
Connecting to Video Sources............... 13
Connecting to Multi-media Devices...... 14
Powering On/Off the Projector ............. 15
Powering On the Projector............... 15
Powering Off the Projector............... 16
LED Indicator Messages.................. 16
Adjusting the Projected Image ............. 17
Adjusting the Projector’s Height....... 17
Adjusting the Projector’s Focus ....... 18
Adjusting Projection Image Size ...... 18
User Controls 19
Using the Control Panel ....................... 19
Using the Remote Control .................... 20
On-screen Display Menus .................... 22
How to operate ................................ 22
Structure .......................................... 23
PICTURE ......................................... 24
PICTURE | Advanced ...................... 26
PICTURE | Advanced | Input ........... 27
SCREEN.......................................... 28
SETTING ......................................... 29
SETTING | Signal (RGB) ................. 31
SETTING | Advanced....................... 32
SETTING | Advanced | Security....... 33
OPTIONS......................................... 35
OPTIONS | LED Settings................. 37
OPTIONS | Advanced ...................... 38
Media Arena ......................................... 39
How to operate ................................ 39
Structure .......................................... 42
SETUP............................................. 42
SETUP | Photo Setting .................... 43
SETUP | Music Setting .................... 44
SETUP | Video Setting..................... 45
SETUP | Firmware Upgrade ............ 46
Internal Memory............................... 47
File Transfer..................................... 47
Projection with Wireless Presentation .. 48
Projection with MobiShow .................... 49
MobiShow Utility for iPhone............. 49
MobiShow Utility for Android............ 50
Using the MobiShow........................ 50
MobiShow | Photo Viewer................ 51
MobiShow | PtG2............................. 52
Using the PtG2 Converter................ 53
Appendices 54
Troubleshooting.................................... 54
Image Problems............................... 54
Projector Problems .......................... 57
Multi-media Problems ...................... 57
On Screen Messages ...................... 58
Piscel Support Languages, Character
Encodings and Fonts............................ 59
Compatibility Modes ............................. 64
Multi-media Format Supported............. 68
Ceiling Mount Installation ..................... 70
6SHFL¿FDWLRQV ....................................... 71

ViewSonic PLED-W500 Specifications

General

Matrix size	0.45 \
Number of colors	16.78 million colors
Projection distance	0.91 - 2.4 m
Vertical scan range	48 - 120 Hz
Horizontal scan range	31 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	6000:1
Screen size compatibility	30 - 80 \
Projector native resolution	WXGA (1280x800)
Keystone correction, vertical	-40 - 40 °
Aspect ratio	16:10
RS-232 ports	-
Network ready	No
Dimensions (WxDxH)	214 x 164 x 42 mm
Connectivity technology	Wired
Maximum analog resolution	1680 x 1050 pixels
Maximum digital resolution	1920 x 1080 pixels
Focus	Manual
Focal length range	- mm
Lamps quantity	1 lamp(s)
Light source type	LED
Service life of light source	20000 h
PC Audio in	Yes
USB connector type	USB Type-A
USB 2.0 ports quantity	2
S-Video inputs quantity	1
Ethernet LAN (RJ-45) ports	0
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	1440 x 1050, 1680 x 1050 (WSXGA+), 640 x 480 (VGA)
RMS rated power	2 W
Audio formats supported	MP3
Video formats supported	H.264, MPEG2, MPEG4
Product color	Black
Market positioning	Portable
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	144 W
Compatible memory cards	SD
Internal storage capacity	0.5 GB
Noise level	38 dB
Certification	CE, CB, UL, cUL, FCC (including ICES-003), NOM, TUV-S Argentina, RoHS
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	VGA

Weight and Dimensions

Weight	1180 g
