22
AV IN Connecon
To connect your peripheral device(s) via AV:
1. Connect a 3-color AV cable from the AV IN ports on your ViewBoard to the AV
OUT ports of a peripheral device
NOTE: On the AV cable: Yellow is Video, Red is Audio-R, White is Audio-L.
2. Plug in the power cord of your ViewBoard, and turn on the rear-panel power
supply switch.
3. Press the
Power button on the right-hand side of the ViewBoard to turn the
screen on.
4. Press the INPUT button to switch to the “AV” input source.
