ViewSonic VSD220 User Manual

Set Up Your VSD220 Smart Display
6
2.3 Turn On Your Device
Press and hold power button about 1-2 seconds
Slide the lock icon to unlock the screen
1
After connecting the power cord, you can press and hold the power
button about 1-2 seconds on the lower right corner to power on your
device.
2
Once powered-up, the LED indicator will show solid Green.
3
The lock screen will appear after a short boot-up period.
4
Touch and slide the lock icon to unlock the screen.
5
The device is ready for use when the Home screen is displayed.
2.4 Turn Off Your Device
1
Press and hold the power button more than 4 seconds.
2
When the power off menu appears, touch OK.

ViewSonic VSD220 Specifications

General

Processor cores	2
Processor family	-
Processor frequency	1 GHz
Internal memory	1 GB
Maximum internal memory	- GB
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	8 GB
Compatible memory cards	MicroSD (TransFlash)
Megapixel	1.3 MP
Chassis type	All-in-One
Power supply type	AC/DC
Dimensions (WxDxH)	512.8 x 21.9 x 353 mm
USB connector type	Micro-USB A
Storage drive average seek time	5 ms
Display diagonal	21.5 \
Touch technology	Multi-touch
Display brightness	250 cd/m²
Native aspect ratio	16:9
Contrast ratio (typical)	1000:1
RMS rated power	3 W
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.1+EDR
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Product color	Black
Operating system installed	Android 4.0
AC adapter input voltage	100 - 240 V
Power consumption (typical)	40 W
Cables included	AC
Certification	UL/cUL, CE, CB, FCC-B(including ICES003), CCC, Gost-R/Hygienic, China Energy
Sustainability certificates	RoHS

Weight and Dimensions

Package weight	5800 g
Depth (with stand)	21.9 mm
Width (with stand)	512.8 mm
Height (with stand)	353 mm
Weight (with stand)	4800 g
